Surface-mounted housing with rain cover for six modules
The housing that holds the modules if you do not want to cut a recess in the wall. It has a rain cover, so that water running down the facade does not flow over the modules.
Space for six modules, arranged in two rows of 3. The front panel that covers the whole is a separate item: two pieces of VTM24P3 are required.
What you can count on
- Surface mounting on the wall: no chasing or routing required, the housing sits against the façade
- Built-in rain cover: the cover extends over the modules
- For six modules: two rows of 3 side by side
- Front panel separate: this requires two pieces of VTM24P3
The front panel is not included
The housing and the front panel are two separate items. The box contains only the housing; the front panel must be ordered in addition.
These housings are designed for Dahua modular door stations. If you are not sure whether your modules fit, please send us the model type and we will check.
The details at a glance
| Function | Surface-mount housing with rain cover |
| Number of modules | 6 (3 x 2) |
| Mounting | Surface-mount, on the wall |
| Colour | Black |
| Dimensions | 341,4 x 281,5 x 75,2 mm |
| Weight | 1,59 kg |
| Front | VTM24P3 |
| Model code | VTM29R6 |
The full specification is in the Dahua datasheet.
Frequently asked questions
Is the front panel included?
No. Order two pieces of VTM24P3 as well, otherwise the housing remains open.
Can this housing also be installed in the wall?
No, this is the surface-mount version with rain cover. For flush mounting there are separate mounting boxes: the VTM79, VTM127 and VTM128.
How many modules fit in it?
Six, in two rows of 3. Include the camera module in the count: it takes up a position itself.
Does the rain cover keep everything dry?
The cover catches the water that runs down the façade. Seal the edges with silicone sealant during installation, otherwise moisture can still get behind the housing.
